|power sUPPLY:||9...30.3V||cURRENT CONSUMPTION W/PANEL ILLUMINATION:||500 mA at27.5 V|
|oPERATING TEMPERATURE:||-20...+55°C||SHORT TIME TEMPERATURE:||+70°C|
|STORAGE TEMPERATURE:||-55...+85°C||ALTITUDE MAX:||50 000 ft.|
|memeory capacity xpdr:||1 Code||mtbf:||5000 hours|
|speed:||COM 9.6 kbps, NAV 9.6 kbps, ADF 9.6 kbps, XPDR 4.8 kbps, RMU 19.2 kbps||data transfer:||TTL level (positive logic), 0: groun(less than 22 Ω or 0...3.5 VDC), 1: +5 VDC (sinking up to 25 mA), Z: more than 100 k to ground|
|self test:||Built in Test (PBIT, CBIT, IBIT)||DISPLAY TECHNOLOGY:||LCD (positive) with backlight monochrome|
|effective display resolution:||86x31 pixels||view angle:||45°with 12 o'clock preferred viewing angle|
|backlight color:||Amber||LED COLOR:||Amber|
|weight:||DZUS version: <0.75 kg, 160 mm version: <0.09 kg (including mounting frame)||dimensions :||DZUS version:56.8H x 145.8 W x 172.2mm D(2.24 x 5.74 x 6.77 inch), 160 mm version:59.8 H x 160 W x 172.2mm D(2.35 x 6.3 x 6.77 inch)|
|panel color:||RAL 9005 (black)|
|REQUEST||NEW OUTRIGHT||REQUEST LEAD TIME|
