|$575.00||SV OUTRIGHT||1 IN STOCK||VIEW|
|$5,650.00||NEW OUTRIGHT||REQUEST LEAD TIME||
|Size:||3.25"W x 3.25"H x 9.85"L||Weight:||1.6 lbs.|
|TSO (VOR):||FAA TSO C40a Operation above 15,000 ft.; DO 114 (by FAA approval)||TSO (LOC):||FAA TSO C36c Class D; RTCA DO 131|
|Typical Accuracy (VOR):||(VOR) Bearing error less than 1.7 degrees. Full scale deflection for 10 deg. course error.||Typical Accuracy (LOC):||(LOC) Centering error less than 3uA. Three fifths delfection for 4dB tone ratio|
|Converter Inputs:||.5VRMS +-10% ARINC phasing (VOR Composite Input); 100k ohms (Input Impedance)||Converter Output Drive Capability:||Five 1K loads 150 uA full scale (VOR/LOC Deviation); Two 200 ohm, 200-0-200uA loads (TO/FROM); Five 1K ohm, 0-260uA loads (VOR/LOC Warning Flag)|
|Course Datum Synchro Output:||393mV/degree, 1 deg. Accuracy Typical||Course Datum Synchro Input:||Standard ARINC X,Y,X 11.8VRMS; .030AMP; 400Hz|
|066-3034-00||Black bezel, 14/28 volt white lighting, VOR/LOC Converter, VOR/LOC needle, NAV flag, TO/FROM flag, 30Hz OBS resolver|
|066-3034-01||Black bezel, 14/28 volt white lighting, VOR/LOC Converter & needle, NAV flag, TO/FROM flag, 30Hz OBS resolver, Course Datum Synchro|
|NOTE:||Same base part number used for all KI-202/203/204/206/207 indicators|
|Shop||Southeast Aerospace Inc.|
|$575.00||SV OUTRIGHT||1 IN STOCK|
|$5,650.00||NEW OUTRIGHT||REQUEST LEAD TIME|
Click on a question below to see the answer. If you have a question about this model that is not answered below, please contact email@example.com
In relation to NE (New) parts, many OEMs change their prices and availability without any notice to dealers or the industry. Therefore, through the REQUEST or RFQ indication, we ask that customers contact us for the most accurate price and availability.
In relation to SV & OH parts, the used parts aftermarket in the aviation industry is not an infinite supply. It is a dynamic, constantly changing market that is significantly affected by and susceptible to highs and lows in supply and demand. Therefore, although we attempt to, at times, we are unable to predict the exact moment when an item may be available. Once again, through the REQUEST or RFQ indication on our website, we ask that customers contact us for the most current and accurate price and availability.
