Part #:

Model: DBU-5000

Collins Aerospace - Data Base Unit
product image
Part Number :


DBU-5000
FEATURES
  • Database Unit
  • Faster database updates
  • Eliminates floppy disks and laptop connections
  • Enables simultaneous loading of multiple databases
  • Simplified operation
  • All databases for an aircraft can fit on a single USB memory device
  • Improved flexibility
  • FMS database updates available for download from anywhere in the world over the internet
  • Simple Installation
  • Drop-in replacement for the DBU-4000 and DBU-41000 to enable FMS database loading
  • For ProLine 21 operators with IFIS installed, CPAS removal and wiring changes enable IFIS updates using the DBU-5000
  • Growth capability for even faster uploads
  • FMS V4.X improved bus speed

SPECIFICATIONS

cERTIFICATION: The DBU-5000, DBU-5010/E is certified in accordance with TSO C113. The DBU is considered to be support equipment for data selected LRU's size: 1/4 , short-low case
mounting information: Four Dzus fasteners coolining requirements: The DBU's are natural convention cooled
power requirements: 28.0 V dc (32.2 V dc max, 18.0 V dc min.), 12.0 Watts (Max.) rtca documents: Evironment conditions and test procedures for Airborne Equipment: DBU-5000, -5010: DO-160E(). DBU-5010E: DO-160F, DO-178 (Software Considerations in Airborne System and Equipment Certification)
wieight: 0.725 kg (1.6 lbs) nominal, sliding door, 0.770 kg (1.9 lbs) nominal, flip door length: 168.91 mm (6.650 in) max
height: 57.15 mm (2.250 in) max.





Part Number Database Unit:
822-2215-001 Sliding Door, Black bezel, AFIS Interface, No Ethernet Interface
822-2215-002 Sliding Door, Medium Gray bezel, AFIS Interface, No Ethernet Interface
822-2215-003 Sliding Door, Silver Metallic Gray bezel, AFIS Interface, No Ethernet Interface
822-2215-101 Sliding Door, Black bezel, No AFIS Interface, No Ethernet Interface
822-2215-102 Sliding Door, Medium Gray bezel, No AFIS Interface, No Ethernet Interface
822-2215-103 Sliding Door, Silver Metallic Gray bezel, No AFIS Interface, No Ethernet Interface
822-2215-201 Sliding Door, Black bezel, No AFIS Interface, Ethernet Interface
822-2215-202 Sliding Door, Medium Gray bezel, No AFIS Interface, Ethernet Interface
822-2215-203 Sliding Door, Silver Metallic Gray bezel, No AFIS Interface, Ethernet Interface
822-2215-301 Sliding Door, Black bezel, AFIS Interface, Ethernet Interface
822-2215-302 Sliding Door, Medium Gray bezel, AFIS Interface, Ethernet Interface
822-2215-303 Sliding Door, Silver Metallic Gray bezel, AFIS Interface, Ethernet Interface
822-2215-401 Flip Door, Black bezel, AFIS Interface, No Ethernet Interface
822-2215-402 Flip Door, Medium Gray bezel, AFIS Interface, No Ethernet Interface
822-2215-403 Flip Door, Silver Metallic Gray bezel, AFIS Interface, No Ethernet Interface
822-2215-501 Flip Door, Black bezel, No AFIS Interface, No Ethernet Interface
822-2215-502 Flip Door, Medium Gray bezel, No AFIS Interface, No Ethernet Interface
822-2215-503 Flip Door, Silver Metallic Gray bezel, No AFIS Interface, No Ethernet Interface
822-2215-601 Flip Door, Black bezel, No AFIS Interface, Ethernet Interface
822-2215-602 Flip Door, Medium Gray bezel, No AFIS Interface, Ethernet Interface
822-2215-603 Flip Door, Silver Metallic Gray bezel, No AFIS Interface, Ethernet Interface
822-2215-701 Flip Door, Black bezel, AFIS Interface, Ethernet Interface
822-2215-702 Flip Door, Medium Gray bezel, AFIS Interface, Ethernet Interface
822-2215-703 Flip Door, Silver Metallic Gray bezel, AFIS Interface, Ethernet Interface



822-2215-001
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-002
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-003
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-101
- Database Unit
Price Condition Status
REQUEST SV OUTRIGHT REQUEST
REQUEST SV EXCHANGE REQUEST
822-2215-102
- Data Base Unit (Sliding Access Door, Gray)
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-103
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-201
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
REQUEST SV OUTRIGHT REQUEST
REQUEST SV EXCHANGE REQUEST
822-2215-202
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-203
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-301
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-302
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-303
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-401
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-402
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-403
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-501
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-502
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-503
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-601
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-602
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-603
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-701
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-702
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
822-2215-703
- Data Base Unit
Price Condition Status
REQUEST NEW OUTRIGHT REQUEST
