Picture of product BT200-1100

Part #: 1001561

Model: BT200-1100

OEM:

Kannad

Desc:

Beacon Tester

Part Number :

FOR REFERENCE ONLY

Image result for kannad logo images

BT200-1100

FEATURES
  • The BT200 beacon tester follows in the footsteps of the popular BT100.
  • The BT200 is more accurate, inherently rugged, and intuitive to use.
  • Packaged in a handheld design, the BT200 beacon tester performs code verification, annual certifications, inspections, troubleshooting, and tests all Cospas-Sarsat 406 ELTs and older C91a ELTs without requiring expensive equipment
  • Compact and rugged with an integrated receiver
  • Android operating system
  • Waterproof and rugged construction with an IP68 rating
  • Receives all Cospas-Sarsat frequency channels and ELT protocols
  • Measures RF parameters along with modulation details on 406, 121.5 and 243 MHz
  • Powerful 406 MHz graphic measurements for power, phase modulation and in-band spectrum
  • Internal antenna receives 406 MHz burst up to 10 meters away or directly connect the beacon to tester at 50
  • Receives full RF power with no attenuator required
  • Add text, audio, photos or videos to each measurement
  • User-defined cable loss factor
  • Easy to use file system



SPECIFICATIONS

DIMENSIONS: 2.76 x 2 x 5.31 in.
Weight: 0.49 lbs.
vswr: 1.20:1
operating temperature: +5°C to +50°C
RF CABLE TERMINATION: BNC Female
RF RANGE: 406 MHz. 121.5 MHz, 243 MHz





Part Number: Description:
1001561 Beacon Tester
