Picture of product ART-7000
Part #: 69003810-101
Model: ART-7000
Desc: RDR-7000 Weather Radar Transceiver
OEM: Honeywell
ECCN: 6A998.a
Part Number :

ART-7000

The Honeywell IntuVue RDR-7000 is an advanced, fully automatic weather radar system designed specifically for business and general aviation aircraft. This lightweight unit (just 13 lbs) delivers superior weather detection and analysis without requiring manual pilot adjustments to tilt or gain, significantly reducing workload and allowing pilots to concentrate on safe, efficient flight paths.

Key highlights include automated 3D volumetric scanning up to 60,000 feet altitude and 320 nautical miles ahead, providing crystal-clear visualization of storms, hail, windshear, and turbulence. With an impressive 93% accuracy in turbulence prediction, it helps reduce turbulence-related incidents by over 50% and improves weather avoidance decision-making by 26%. The system outperforms legacy magnetron-based radars in reliability, accuracy, and durability.

Ideal for retrofits, the RDR-7000 offers near plug-and-play installation when replacing older Honeywell Primus models (such as P700/701, P440/660/880), making upgrades straightforward and cost-effective. Remote software upgrades enable additional advanced features for enhanced performance tailored to your routes.

Benefits for operators:

  • Enhanced safety for pilots and passengers through better storm detection and rerouting
  • Fewer delays, diversions, and downtime from severe weather events
  • Optimized fuel efficiency and lower operational costs
  • Available with 12-inch or 18-inch antenna options
  • See even more benefits below!

Elevate your aircraft's weather radar capabilities with the Honeywell IntuVue RDR-7000 – the smart choice for reliable, intuitive weather awareness in modern aviation.



* Avoid rising repair costs, expired warranties, and outdated technology. Upgrade to one of the smartest, most intuitive weather radars available!



FEATURES

Operational Benefits

  • Automatic weather detection modes
  • 3-D Volumetric Scan Buffer
  • Integral terrain database for ground clutter elimination
  • Extended ground map mode
  • Enhanced Turbulence detection
  • Hail & lightning detection
  • Improved hazardous weather and turbulence prediction
  • Improved windshear prediction (Phase 2 addition)
  • Nearly “drop-in” replacement to current installed unit
  • On-Path/Off-Path weather with hazard symbologyAutomatic weather detection modes

Performance Benefits

  • Minimize pilot manipulation/interaction
  • Increased range performance and higher resolution with Honeywell’s patented pulse compression technology
  • Solid state gallium arsenide transmitter providing direct amplification
  • Improved windshear performance – including significant reduction in false alerts
  • Improved turbulence detection
  • Direct drive antenna provides greater pointing accuracy

Reduced life cycle costs

  • Reduced size, weight & power (over comparable radar) – 1 LRU package
  • Elimination of magnetrons with use of solid-state gallium arsenide transmitter
  • Digital radio techniques eliminate tuning points providing improved repeatability, reliability, and lower drift
  • Elimination of gears in the antenna drive system
  • On-board high-speed Ethernet software data loading
  • Enhanced BITE and fault logging by flight leg
  • Removable compact flash memory for software loading
  • Greatly increased reliability
  • No forced air cooling required



SPECIFICATIONS

input power:  28 VDC POWER DISSIPATED: 70 W (LRU Consumption) 32.4 transmitted
Weight: 13 lbs. (5.9 kg) Without Antenna environmental:  DO-160G (-55°C to +70°C)
SOFTWARE: RTCA DO-178C fLAT PLATE: 12" and 18"
trasmitter type: Solid State Gallium Nitride (GaN) TRANSMITTER mETHOD:  Pulse Compression
Elevation coverage: 0 to 60,000 ft. aZIMUTH COVERAGE: +/- 60 Degs - Weather and Group Map, +/- Windshear
max detection ranges: 320 nm -Weather and Group Map, 60 nm - Turbulence, 5 nm - Windshear tso: TSO-C63f Equipment Classes A, B, C, D


Part Number: Description:
69003810-101 Weather Radar Transceiver



Serial # ART7K01216
Condition NEW
Mods 1-3
Tag Date 08/15/25
Shop Honeywell International Inc.
Warranty 1 Year
69003810-101
- RDR-7000 Weather Radar Transceiver
Price Condition Status
REQUEST NEW OUTRIGHT 1 IN STOCK
