Part #: | CI-177-13 |
---|---|
Model: | CI-177-13 |
Desc: | FM Extended Band Antenna |
OEM: | Comant |
NSN: | |
---|---|
Sched-B: | 8529104000 |
ECCN: | 7A994 |
Price | Condition | Status | More Info | |
---|---|---|---|---|
$895.00 | NEW OUTRIGHT | REQUEST LEAD TIME |
|
CI-177-13
FEATURES
SPECIFICATIONS
fREQUENCY: | 138 to 174 MHz | Weight: | 0.5 lbs. max |
Finish: | White Polyurethane Enamel | vswr: | 2.5:1 MHz Maximum |
polarization: | Vertical | radiation pattern: | Omniderctional |
impedance: | 50 Ohms | power rf: | 50 Watts |
height: | 14.50 in. Maximum | material: | Die Cast housing/Fiberglass whip |
connector: | BNC (Female) | air speed: | 450 Knots TAS at 25,000 ft. |
gasket: | C29205 | TEMPERATURE: | -55°C to +55°C |
ALTITUDE: | 30,000 ft. | rtca: | DO-138 |
FAA TSO: | C37b, Class1, C38b | Environmental CATEGORY: | BAJXXXXXXXXXXX |
Part Number | Description: |
---|---|
CI-177-13 | FM Extended Band Antenna |
Price | Condition | Status |
---|---|---|
$895.00 | NEW OUTRIGHT | REQUEST LEAD TIME |
