Picture of product ART-7000
Part #: 69003810-101
Model: ART-7000
Desc: RDR-7000 Weather Radar Transceiver
OEM: Honeywell
ECCN: 6A998.a
Part Number :




ART-7000

FEATURES

Operational Benefits

  • Automatic weather detection modes
  • 3-D Volumetric Scan Buffer
  • Integral terrain database for ground clutter elimination
  • Extended ground map mode
  • Enhanced Turbulence detection
  • Hail & lightning detection
  • Improved hazardous weather and turbulence prediction
  • Improved windshear prediction (Phase 2 addition)
  • Nearly “drop-in” replacement to current installed unit
  • On-Path/Off-Path weather with hazard symbologyAutomatic weather detection modes

Performance Benefits

  • Minimize pilot manipulation/interaction
  • Increased range performance and higher resolution with Honeywell’s patented pulse compression technology
  • Solid state gallium arsenide transmitter providing direct amplification
  • Improved windshear performance – including significant reduction in false alerts
  • Improved turbulence detection
  • Direct drive antenna provides greater pointing accuracy

Reduced life cycle costs

  • Reduced size, weight & power (over comparable radar) – 1 LRU package
  • Elimination of magnetrons with use of solid-state gallium arsenide transmitter
  • Digital radio techniques eliminate tuning points providing improved repeatability, reliability, and lower drift
  • Elimination of gears in the antenna drive system
  • On-board high-speed Ethernet software data loading
  • Enhanced BITE and fault logging by flight leg
  • Removable compact flash memory for software loading
  • Greatly increased reliability
  • No forced air cooling required



SPECIFICATIONS

input power:  28 VDC POWER DISSIPATED: 70 W (LRU Consumption) 32.4 transmitted
Weight: 13 lbs. (5.9 kg) Without Antenna environmental:  DO-160G (-55°C to +70°C)
SOFTWARE: RTCA DO-178C fLAT PLATE: 12" and 18"
trasmitter type: Solid State Gallium Nitride (GaN) TRANSMITTER mETHOD:  Pulse Compression
Elevation coverage: 0 to 60,000 ft. aZIMUTH COVERAGE: +/- 60 Degs - Weather and Group Map, +/- Windshear
max detection ranges: 320 nm -Weather and Group Map, 60 nm - Turbulence, 5 nm - Windshear tso: TSO-C63f Equipment Classes A, B, C, D


Part Number: Description:
69003810-101 Weather Radar Transceiver



69003810-101
- RDR-7000 Weather Radar Transceiver
Price Condition Status
REQUEST NEW OUTRIGHT DUE IN 8/29/2025

Click on a question below to see the answer. If you have a question about this model that is not answered below, please contact questions@seaerospace.com


In relation to NE (New) parts, many OEMs change their prices and availability without any notice to dealers or the industry. Therefore, through the REQUEST or RFQ indication, we ask that customers contact us for the most accurate price and availability.

In relation to SV & OH parts, the used parts aftermarket in the aviation industry is not an infinite supply. It is a dynamic, constantly changing market that is significantly affected by and susceptible to highs and lows in supply and demand. Therefore, although we attempt to, at times, we are unable to predict the exact moment when an item may be available. Once again, through the REQUEST or RFQ indication on our website, we ask that customers contact us for the most current and accurate price and availability.
