Part #: S67-2002-45

Model: S67-2002-45

Sensor Systems - Radio Altimeter Antenna
product image
Part Number :


S67-2002-45
FEATURES
  • Flush Mounted Radio Altimeter Antenna
  • Circular baseplate requires mounting with eight (8) screws
  • Compaitlbe with 7" diameter horns
  • Provides improved performance and reduced size and weight
  • Ideal for general aviation application
  • Federal & Military Specs: FAA TSO C87, ARINC 707/552, DO-160, MIL-STD-810, MIL-A-9094, MIL-B-5087, MIL-E-5400
  • Suggested to replace 437X-1 and KA-54



SPECIFICATIONS
Frequency: 4200-4400 MHz VSWR: 2.0:1 (4200-4400) 1.5:1 (4275-4325)
Polarization: Linear Impedance: 50 ohms
Beam Width: Roll Plane (E) :45° min Pitch Plane (H) :40° min.  Power Handling: 5 w/avg. 500 w/peak
Side Lobe Level: -40 dB Gain: 9.5 dBi
Lightning Protection: DC grounded  Weight: 8 oz
Dimensions: .15" H x 7" D Material: 6061-T6 aluminum / teflon glass
Finish: Skydrol-resistant enamel  Connector: TNC
Temperature:  -65°F to +185°F  Vibration:  10 G's
Altitude:  -1000 ft to +45000 ft  Isolation H-Plane: 16" 80 dB; 20" 88 dB; 30" 90 dB; 36" 95 dB






Part Number Radio Altimeter Antenna Description:
S67-2002-45 see details above



S67-2002-45
- Radio Altimeter Antenna

NSN: 5985-01-641-5449
