|Input Voltage:||10 VDC to 40 VDC, reverse polarity protected||GPS Input Power:||7 watts typical|
|Comm Input Power:||3.7 watts typical receive 28 watts typical transmit||Height:||2.00 inches|
|Width:||6.25 inches||Depth:||11.125 inches|
|Weight:||3.1 lb||Operating Temperature:||-20C to +55C|
|Maximum Altitude:||35,000 ft||Number of Channels:||8|
|Frequency:||1575.42 MHz L1, C/A code||Sensitivity (acquisition):||-135dBm|
|Sensitivity (drop lock):||-142dBm||Dynamic Range:||>20 dB|
|Lat/Lon position accuracy:||15 meters RMS typical 25 meters, SEP, without SA 100 meters 2DRMS with SA||Velocity:||1000 knots maximum|
|Acceleration:||4G maximum||Time to First Fix:||25 seconds typical|
|Reacquisition:||2.5 seconds typical||Position Update Interval:||1 second typical|
|Datum:||WGS-84||Comm Output Power:||8 watts minimum carrier at > 12VDC input 6 watts minimum carrier at 10VDC input|
|GPS Approvals:||TSO C129a Class A1||Comm Approvals:||TSO C37d transmit TSO C38d receive TSO C128 Stuck mic|
Click on a question below to see the answer. If you have a question about this model that is not answered below, please contact firstname.lastname@example.org
In relation to NE (New) parts, many OEMs change their prices and availability without any notice to dealers or the industry. Therefore, through the REQUEST or RFQ indication, we ask that customers contact us for the most accurate price and availability.
In relation to SV & OH parts, the used parts aftermarket in the aviation industry is not an infinite supply. It is a dynamic, constantly changing market that is significantly affected by and susceptible to highs and lows in supply and demand. Therefore, although we attempt to, at times, we are unable to predict the exact moment when an item may be available. Once again, through the REQUEST or RFQ indication on our website, we ask that customers contact us for the most current and accurate price and availability.
