Part #: 980-6023-002

Model: AR-120

OEM:

Honeywell

Desc:

AR CVR (120 Minute)

Part Number :


AR-30
FEATURES
  • Advanced LIghtweight crash survivable Solid State cockpit voice recorder
  • Non-ARINC form factor
  • Intended for installation in general aviation aircraft and helicopters
  • Simultaneously records up to four channels of audio and retains most recent 120 minutes
  • Chassis consists of three easily replaceable (SRUs) - Controller board, Crash Survivable Memory Unit (CSMU) and Input and Power Supply board
  • 28 Volt
  • Underwater Locator Beacon (ULB)
  • Normal system consists of recorder unit and pre-amplified remote area microphone (P/N 980-6113-010)
  • Does not require installation rack since chassis has a flange that assists in attaching unit directly to airframe using 6 pan head screws P/N MS51958-63 or equivalent
  • Unit mates with KJ6F16N35S (Cannon #) or 440-0674-007 (Honeywell #) crimp connecor kit
SPECIFICATIONS
Temperature Range: -55 to 70 Altitude: 50000 ft.
Weight: 9.2 lbs. Dimensions: 4.88"W x 5.60"H x 9.15"L
Recording Time: 30 minutes TSO: 123a/ED-56a
Part NumberAdvanced Cockpit Voice Recorder Description:
980-6023-002 see details above



980-6023-002
- AR CVR (120 Minute)
Price Condition Status
REQUEST SV OUTRIGHT REQUEST LEAD TIME
